Load flow is also referred to as power flow; these terms may be interchangeably used. This is the name given to a network solution that predicts steady-state currents, voltages, and real and reactive power flows through every branch and bus in the system.

Load-flow studies simulate operating conditions that cannot practically be experienced on the actual system because the system has not yet been built, because of the practical constraints of time, or because it would be unwise to expose the actual physical system to conditions that are potentially damaging.

Load flow analysis has a great importance:

1. To verify the operation of a network under various load and generation conditions
2. To plan the future growth of both loads and generation
3. To determine the best economical operation for existing systems
4. To establish initial conditions for stability studies
5. To help identify the need for additional capacitive or inductive VAR support, to maintain system voltages within acceptable limits

Also, load flow results are very valuable for setting the proper protective devices to avoid nuisance tripping and improve system reliability

Reference Standard: IEEE Std 3002.2, IEEE Std 399, IEEE Std 141
